Kronos Class S Autoclave - 23L

AUTOCLAVE KRONOS CLASS S - 23L

The Kronos Class S Autoclave - 23L is an advanced solution for safe and efficient sterilization, designed for professional environments that require greater capacity. With a capacity of 23 liters, it offers high performance, advanced features, and maximum safety, making it ideal for medical offices, clinics, laboratories, and surgical centers.

General Features

VSL - Vacuum Safety Locking

The VSL (Vacuum Safety Locking) technology ensures that the autoclave door seals perfectly during the sterilization cycle. This motorized system guarantees that the chamber is securely vacuum-sealed and does not open during the process, minimizing risks and enhancing safety.

Water Purification System (ROSI)

The reverse osmosis (ROSI) purification system ensures that the water used in the autoclave is free from impurities. With micro-pores of 0.0001 micron, the water is purified highly effectively. The system can be connected to the water supply, providing ultra-pure water for optimal sterilization (optional).

Water Quality Meter

The autoclave is equipped with a conductivity meter that monitors water quality during the sterilization cycle. Values are continuously transmitted to the user to ensure that the water is always ultra-pure, essential for achieving perfect sterilization cycles.

USB Archive

All sterilization cycles are automatically recorded on a USB flash drive, allowing for easy data download to a PC via the provided software (optional). This archiving system makes it easy to monitor cycles and document data.

Multilingual and User-Friendly Display

The autoclave display is intuitive and available in multiple languages. With 4 control buttons, navigating through the various sterilization options is simple and quick. The display provides information on the ongoing cycle, alerts for any errors, and notifies when assistance is needed.

Integrated Thermal Printer

The autoclave is equipped with an integrated thermal printer that records each sterilization cycle. This printer provides paper documentation that can be stored alongside files to ensure traceability and complete control of the sterilization process.

TECHNICAL SPECIFICATIONS:

• Type of Vacuum: Pre and Post vacuum for deep and complete sterilization.
• Integrated Steam Generator: To ensure continuous steam production during the sterilization cycle.
• Integrated printer;
• M.T.S. Memory Test System: System to test memory and ensure that data is correctly stored.
• Water Quality Meter: To monitor water purity during each cycle.
• Connection to Data Logger: Optional for advanced monitoring of sterilization data.
• USB Data Logger: Optional, to record and store cycles on a USB flash drive.
• "ROSI" Water Purification System: Optional, for high-quality reverse osmosis water purification.

Dimensions and Power

• External dimensions: 505 L x 690 D x 400 H mm;
• Chamber dimensions:ø236x530 mm;
• Tray dimensions: 4 aluminum trays: 185 L x 440 D x 18 H mm;
• Power supply voltage: 230V ± 10%;
• Network frequency: 50-60 Hz;
• Rated power: 2400W.
