UTC2 GIMA - ULTRASOUND + ELECTROTHERAPY

UTC2 GIMA is a professional unit for ultrasound therapy and electrotherapy, designed for physiotherapy, rehabilitation, and instrumental treatments that require flexibility and precision. The device integrates continuous or pulsed ultrasound and 2 independent electrotherapy channels, allowing for comprehensive treatment management with a single device.

The system supports ultrasonic transducers with frequencies from 1 to 3 MHz, with programmable intensity and delivery time. The handles can also be used in immersion, a useful feature for specific therapeutic applications. On the electrotherapy front, the device offers various currents, including diadynamic, faradic, galvanic, impulsive, TENS, and bipolar.

Operational management is simple and intuitive thanks to the high-brightness touchscreen and the option to use it via knob, keyboard, or touchscreen. The automatic recognition of the connected accessory, preset programs, customizable memories, and the safety system that interrupts the current in case of accidental electrode disconnection make the device suitable for daily professional use.

Main advantages

• Combined unit for ultrasound + electrotherapy
• 2 independent channels
• Multifrequency handle 1-3 MHz
• Continuous or pulsed ultrasound
• Preset and customizable programs
• High-brightness touchscreen
• Automatically recognized accessories
• Safety system on electrode disconnection
• Made in Italy

Technical specifications

• Ultrasound frequency: 1.0 - 3.0 MHz
• Maximum intensity: 3.0 W/cm²
• Electrotherapy channels: 2
• Maximum direct current: 30 mA
• Maximum impulsive current: 70 mA
• Maximum output voltage: 100 Vdc
• Input power: 70 VA
• Power supply: 90-240 V / 50-60 Hz

Standard equipment

• Ultrasound handle 1-3 MHz Ø 35 mm
• Connection cable for electrotherapy 1-2
• 4 rubber electrodes 120x80 mm
• 4 rubber electrodes 45x60 mm
• 3 elastic bands with Velcro
• Power cable 2 m

RDM (NSIS): 1340317

CND: Z120610
