Portable ultrasound for skin LTD990

Wi-Fi Handheld Ultrasound LTD 990 16/20 MHz, ultra-high resolution, wireless, portable, for dermatology and aesthetic medicine.

  • -€1,870.00
  • Save €1,870.00
€6,820.00
€4,950.00 Save €1,870.00
VAT excluded
Quantity

Add to favorites
Add to wishlist


Security policy (edit with Customer reassurance module)



Delivery policy (edit with Customer reassurance module)



Return policy (edit with Customer reassurance module)

Wi-Fi Handheld Ultrasound for Skin 16/20 MHz (Model M.LTD 990)

The Wi-Fi Handheld Ultrasound LTD 990 is an advanced tool for dermatological diagnostics and aesthetic medicine, designed to provide precise and detailed images of the skin. With the dual-frequency probe 16/20 MHz, it allows for clear visualization of both the superficial layers and deeper layers of the skin, providing essential information for the assessment of lesions, scars, dermal structures, and post-treatment monitoring.

Compact, lightweight, and completely wireless, the LTD 990 model easily connects to iOS, Android, and Windows devices, allowing for real-time visualization, storage, and sharing of ultrasound images, making it ideal for dermatologists, aesthetic physicians, and skin specialists.

Main Features

  • Variable Frequency (16/20 MHz): The probe allows for extremely detailed assessment of skin conditions at various depths, accurately analyzing the structure of the skin, scars, and dermatological lesions.
  • Wireless Connectivity: The integrated Wi-Fi technology enables easy connection with iOS, Android, or Windows devices to view and store ultrasound images in real-time on smartphones, tablets, or PCs.
  • High Resolution: The system provides ultra-high-definition ultrasound images thanks to the 192 elements and 64 channels, allowing for crystal-clear visibility of skin structures.
  • Multiple Viewing Modes: Available scanning modes include B, B/M, Color, PDI (Pulsed Doppler Imaging), and PW (Pulsed Wave), for a comprehensive analysis of various skin conditions.
  • Advanced Image Adjustments: The device offers features for gain, focus, reverse impulse harmonics, and noise reduction, to obtain optimal images even in challenging conditions.
  • Puncture Guidance: Advanced puncture guidance functions in-plane and out-of-plane, as well as an automatic vascular measurement, which are particularly useful in aesthetic treatments and more complex dermatological diagnoses.
  • Image Storage and Sharing: Captured images and videos can be saved in JPG, MP4, PNG, and DCM formats directly on mobile devices or tablets, allowing for easy sharing and review of data.

Technical Specifications

  • Scanning Mode - Linear scanning of electronic arrays
  • Frequency - 16/20MHz
  • Elements - 192 elements
  • Channels - 64 channels
  • Scanning Depth - 10/20/30/40mm, adjustable
  • Field of View - 25
  • Screen - iOS/Android/Windows screen
  • Support System - iOS, Android, Windows
  • Viewing Mode - B, B/M, Color, PDI, PW
  • Image Adjustment - Gain, focus, reverse impulse harmonics, noise reduction
  • Puncture Auxiliary Function - In-plane puncture guidance, out-of-plane puncture guidance, automatic vascular measurement function
  • Image Gray Scale - 256 levels
  • Noise Reduction - 0-1-2-3-4
  • Gain 30db-105db
  • Dynamic Range - 40/50/60/70/80/90/100/110
  • Image/Video Archive - jpg, MP4, png, DCM, save on smartphones, Tablet PC
  • Measurements - distance, area, obstetrics, and more
  • Power - Built-in lithium battery, 2200mAh, wireless charging can extend working hours indefinitely
  • Cineloop - Manual and automatic, playback frames 100/200/500/1000
  • Wifi Type - 802.11n/2.4G/5G dual-band 450Mbps
  • Battery Life - 1.5 hours
  • Dimensions - 156mm×60mm×20mm
  • Net Weight - 180 grams

The Wi-Fi Handheld Ultrasound LTD 990 represents the ideal solution for those seeking portability, precision, and diagnostic versatility. With its high-frequency probe, ultra-high-resolution imaging, and universal wireless connectivity, it is the modern tool for advanced dermatology and aesthetic medicine, perfect for rapid analyses, treatment monitoring, and accurate diagnoses.

Product Details

M.LTD990

Download

CE CERTIFICATE

CE CERTIFICATE

Download (875.46KB)
